Link Annotations in C# and .NET

PDF Link Annotations are a powerful feature in PDF documents that allow developers to create interactive elements, such as hyperlinks, within a PDF. This function is an interactive element in a PDF document that can:

  • Redirect users to a specific page or section in the same document.
  • Open an external URL in a web browser.
  • Run certain actions, such as opening a file or executing a script.

Below is an example of how this can be done:

  1. Add SautinSoft.PDF from NuGet.
  2. Create a new document and add a page.
  3. Creating settings for text formatting.
  4. Add a text.
  5. Find the text "SautinSoft" and add annotations to the links.
  6. Save the document.

Input file:

Complete code

using System;
using SautinSoft.Pdf;
using System.IO;
using SautinSoft.Pdf.Content;
using SautinSoft.Pdf.Annotations;

class Program
{
    /// <summary>
    /// Text Annotations.
    /// </summary>
    /// <remarks>
    /// Details: https://sautinsoft.com/products/pdf/help/net/developer-guide/link-annotations.php
    /// </remarks>
    static void Main()
    {
        // Before starting this example, please get a free trial key:
        // https://sautinsoft.com/start-for-free/

        // Apply the key here:
        // PdfDocument.SetLicense("...");

        using (var document = new PdfDocument())
        {
            // Add a page.
            var page = document.Pages.Add();

            using (var formattedText = new PdfFormattedText())
            {
                // Set font family and size.
                // All text appended next uses the specified font family and size.
                formattedText.FontFamily = new PdfFontFamily("Calibri");
                formattedText.FontSize = 12;

                formattedText.AppendLine("Hello World");

                // Reset font family and size for all text appended next.
                formattedText.FontFamily = new PdfFontFamily("Times New Roman");
                formattedText.FontSize = 14;
                formattedText.FontStyle = PdfFontStyle.Italic;
                formattedText.Color = PdfColor.FromRgb(1, 0, 0);
                formattedText.AppendLine(" This message was ");

                // Set font style and color for all text appended next.
                formattedText.FontFamily = new PdfFontFamily("Archi");
                formattedText.FontSize = 18;

                formattedText.Append("created by SautinSoft");

                // Reset font style and color for all text appended next.
                formattedText.FontStyle = PdfFontStyle.Normal;
                formattedText.Color = PdfColor.FromRgb(0, 0, 0);

                formattedText.Append(" component!");

                // Set the location of the bottom-left corner of the text.
                // We want top-left corner of the text to be at location (100, 100)
                // from the top-left corner of the page.
                // NOTE: In PDF, location (0, 0) is at the bottom-left corner of the page
                // and the positive y axis extends vertically upward.
                double x = 100, y = page.CropBox.Top - 100 - formattedText.Height;

                // Draw text to the page.
                page.Content.DrawText(formattedText, new PdfPoint(x, y));

                //Find text "SautinSoft" and add Link annotations...
                var text = page.Content.GetText().Find("SautinSoft");
                foreach (var item in text)
                {
                    var link = page.Annotations.AddLink(item.Bounds.Left, item.Bounds.Bottom, item.Bounds.Width, item.Bounds.Height);
                    link.Actions.AddOpenWebLink("https://sautinsoft.com/");
                }
            }
            document.Save("Writing.pdf");
        }

        System.Diagnostics.Process.Start(new System.Diagnostics.ProcessStartInfo("Writing.pdf") { UseShellExecute = true });
    }
}

Download

Option Infer On

Imports System
Imports SautinSoft.Pdf
Imports System.IO
Imports SautinSoft.Pdf.Content
Imports SautinSoft.Pdf.Annotations

Friend Class Program
	''' <summary>
	''' Text Annotations.
	''' </summary>
	''' <remarks>
	''' Details: https://sautinsoft.com/products/pdf/help/net/developer-guide/link-annotations.php
	''' </remarks>
	Shared Sub Main()
		' Before starting this example, please get a free trial key:
		' https://sautinsoft.com/start-for-free/

		' Apply the key here:
		' PdfDocument.SetLicense("...");

		Using document = New PdfDocument()
			' Add a page.
			Dim page = document.Pages.Add()

			Using formattedText = New PdfFormattedText()
				' Set font family and size.
				' All text appended next uses the specified font family and size.
				formattedText.FontFamily = New PdfFontFamily("Calibri")
				formattedText.FontSize = 12

				formattedText.AppendLine("Hello World")

				' Reset font family and size for all text appended next.
				formattedText.FontFamily = New PdfFontFamily("Times New Roman")
				formattedText.FontSize = 14
				formattedText.FontStyle = PdfFontStyle.Italic
				formattedText.Color = PdfColor.FromRgb(1, 0, 0)
				formattedText.AppendLine(" This message was ")

				' Set font style and color for all text appended next.
				formattedText.FontFamily = New PdfFontFamily("Archi")
				formattedText.FontSize = 18

				formattedText.Append("created by SautinSoft")

				' Reset font style and color for all text appended next.
				formattedText.FontStyle = PdfFontStyle.Normal
				formattedText.Color = PdfColor.FromRgb(0, 0, 0)

				formattedText.Append(" component!")

				' Set the location of the bottom-left corner of the text.
				' We want top-left corner of the text to be at location (100, 100)
				' from the top-left corner of the page.
				' NOTE: In PDF, location (0, 0) is at the bottom-left corner of the page
				' and the positive y axis extends vertically upward.
				Dim x As Double = 100, y As Double = page.CropBox.Top - 100 - formattedText.Height

				' Draw text to the page.
				page.Content.DrawText(formattedText, New PdfPoint(x, y))

				'Find text "SautinSoft" and add Link annotations...
				Dim text = page.Content.GetText().Find("SautinSoft")
				For Each item In text
					Dim link = page.Annotations.AddLink(item.Bounds.Left, item.Bounds.Bottom, item.Bounds.Width, item.Bounds.Height)
					link.Actions.AddOpenWebLink("https://sautinsoft.com/")
				Next item
			End Using
			document.Save("Writing.pdf")
		End Using

		System.Diagnostics.Process.Start(New System.Diagnostics.ProcessStartInfo("Writing.pdf") With {.UseShellExecute = True})
	End Sub
End Class

Download
